Configuration and Operation
Page 34 Operating Instructions for KACO blueplanet 3.0-4.6 TL1
Coun-
try-spec.
setting
menu
level
Display/
setting
Action in this menu/meaning
0 1 2 3 1 Def. total yield
You can set the total yield to any value, for example,
when you have received a replacement unit and want to
continue the recording from the present value.
 Select the "Save" button and confi rm with the OK
button.
0 1 2 3 1 Interface
 Assign a unique RS485 bus address to the inverter
(“RS485 address” menu item). The address must
not be the same as that of any other inverter or a
proLOG unit.
0 1 2 3 1 S0 pulse rate  Set the pulse rate of the S0 connection.
0 1 2 3 1 Priwatt
 Open the menu: Press the right arrow button or the
OK button.
0 1 2 3 2 Activation mode
 Select operating mode
NOTE: Re-activation depends on the operating mode
selected and on the activation conditions.
0 1 2 3 2 Monitoring time
 Set time span during which the power threshold
must be exceeded without interruption.
0 1 2 3 2 Power threshold
 Set power threshold from which the monitoring
time up to activation begins.
0 1 2 3 2 Operation mode
 Power-dependent: the function remains active until
below the set power threshold.
 Time-dependent: The function is active depending
on the sunlight for the set operating time.
0 1 2 3 2 Operation time
NOTE: The menu option is only available in the
"Time-dependent" operation mode.
 After connection, the function is active for the set
operating time.
0 1 2 3 1 Quick start
 Reduce the waiting times during the self test by
pressing the “Activate” key.
0 1 2 3 1 Logging interval  Set the time between two log data recordings.
0 1 2 3 1 Log data backup
The inverter supports the backing up of all recorded
yield data to a connected USB storage device.
 Activate or deactivate log data backup.
0 1 2 3 1 Display
 Confi gure the contrast setting for the display.
 Set the length of time without user input after
which the backlighting of the LCD switches off .
 Alternatively: Permanently activate or deactivate the
backlighting by selecting “On” or “Off ”.
