Configuration and Operation
Operating Instructions for KACO blueplanet 3.0-4.6 TL1 Page 31
8.2 Initial start-up
When started for the fi rst time, the inverter displays the confi guration assistant. It takes you through the settings
necessary for the initial start-up.
NOTE
After confi guration is completed, the confi guration assistant does not appear again when the
inverter is restarted. You can then change the country setting only in the password-protected param-
eter menu. The other settings can still be changed in the Settings menu.
NOTE
The sequence of the settings required for initial start-up is preset in the confi guration assistant.
Navigation
 In order to select a setting, press the up and down buttons.
 To select the next menu item, press the OK button.
 To return to the most recently selected menu item, press the ESC button.
 Set the required settings.
Press the OK button in the last menu item.
» You have completed the initial confi guration. The inverter begins to operate.
Initial confi guration
 Select the menu language.
 Select the country of operation with grid type.
 Set the date and time.
 To store the set operator country and grid type permanently, confi rm these settings with "Yes".
» You have completed the initial confi guration. The inverter begins to operate.
8.3 Menu structure
8.3.1 Display on the LCD
1
3
4
2
Figure 32: Main menu
Key
1 Selected menu item 3 Menu items of the active menu level
2 Name of the active menu level 4 Menu items of the next lower menu level
