Installation and commissioning examples
Example using manual IP address assignment
Operating Instructions 119
Configure the power
supply module Select the power supply module from the Individual Module IP drop-down list.
Click inside the enabled Set Static text field and enter "4" (172.31.46.4).
Click the «Set Static» button.
MSEsetup sets the static IP address and performs a reconnect to the modules.
Configure the base
module Select the base module from the Individual Module IP drop-down list.
Click inside the enabled Set Static text field and enter "5" (172.31.46.5).
Click the «Set Static» button.
MSEsetup sets the static IP address and performs a reconnect to the modules.
Set the module
chain to use Static
addressing Click the «Use Static Addressing» button.
A dialog box confirms that all modules have been set to static addressing.
Cycle power for the entire module chain by turning the power off and then back on.
Wait for the Network LED to flash twice per second on all modules.
Click the «OK» button in the dialog box.
MSEsetup performs a broadcast. A dialog box confirms the number of modules
found.
Click the «OK» button in the dialog box to overwrite the configurable module
settings.
10.2.9 Power-off the modules
Power-off Press the Off (supply) side of the power switch to power-off the system.
10.2.10 Mount the EnDat module
Mount EnDat module Mount the MSE 1314 (ID 747503-01) 4-channel EnDat module. Refer to "Mounting a
module", page 19.
Connect base and
EnDat module Connect the base module and the 4-channel EnDat module. Refer to "Connecting
modules", page 20.
