Operating information
Capturing data
100 Operating Instructions
9 Operating information
9.1 Toggle output state
The output for compressed air and I/O modules can be toggled on and off from the
tree.
To toggle output:
Double-click the desired channel in the tree.
The channel output state is toggled and the state is updated in the Data and Master
screens.
9.2 Capturing data
The Data screen is used to capture encoder positions and input/output states.
Minimum, actual, and maximum values are captured in the data screen and exported
to a Microsoft Excel file by default. Data capture settings can be modified in the
Configuration screen. Refer to "Data capture", page 51.
Minimum, actual and maximum data values are also available in the Tree by selecting
their respective tab. A value of 0 will be displayed when no data has been captured.
Data screen options:
Display and capture encoder position data
Minimum
Actual
Maximum
Display and capture input and output state
Delete data
Export data
Excel spreadsheet
Comma separated value (CSV) file
Save data
Comma separated value (CSV) file
