2-65
Control Panel Reference
RS422, Dual Mode
Connect a TNX–CPS cable from the SCP RS422 connector to
the REMOTE connectors of each Performer (the cable has two
connectors at the switcher end, 8 inches apart from one
another). The cable length is sized according to your order.
The maximum length is 4,000 feet (1,200 meters). See the
illustration below.
Dual Mode is best for controlling two Performers. The SCP
left button row will control the switcher you assign to address
0; the right button row will control the switcher you assign to
address 1 or above.
TNX-SCPPanel Performer, Address 0
Performer, Address 1
TNX-CPS Cable,
part number 056830
