2-13
Common Configurations
PC (Performer ASCII) to Performer (cont.)
The following is an example of a Performer ASCII string used to
control a Performer via a PC. The command string will switch
video input number 5 on all levels of the Performer (video, audio
1, and audio 2).
Performer ASCII command strings:
■ Preset string – ^M0007D000501
■ Take string – ^M0003T01
Table 2-1.
ASCI
I
Description
Preset String
Byte 1 ^M carriage return
Byte 2 00 Performer address
Byte 3 07 number of data string characters
CMD D data preset, source to destination
Byte 4 00 level, 00 = all levels
Byte 5 05 input selection
Byte 6 01 output selection
Take Strings
Byte 1 ^M carriage return
Byte 2 00 Performer address
Byte 3 03 number of data string characters
CMD T take the specified destination
Byte 4 01 output selection
