1-11
Functional Description
Table 1-1. Performer Specifications (continued)
Parameter Performanace
AES/EBU Digital Audio Outputs
Audio Data Type Serial Digital conforms to AES3-1991 (ANSI S4.40-1985)
Number of Outputs Two per audio matrix (4 ea. total)
Output Connector Balanced female “D” or unbalanced 75
Ω
BNC
Output Level 1.0Vp-p, ±10%, into 75 Ω BNC connector.
5Vp-p ±20% into 110 Ω balanced Output D connector
(both ±5% and 100KHz to 6MHz)
Operating Modes and Electrical Length
Mode Length
143Mb 38.3 ns
177Mb 37.6 ns
270Mb 36.6 ns
360Mb 35.6 ns
Auto See Above
Direct 26.0 ns (non-reclocked)
Mechanical & Power
Size H-1 Rack Unit, 1.75" (4.45cm); D-10" (25.4cm);
W-EIA standard, 19" (48.3cm)
Weight <15 Lbs (6.75kg)
Temperature Range 0 to 50° C (operational)
Humidity Range 0 to 95% non-condensing (operational)
Operational Range 0-250V AC, 50/60Hz, <45 Watts
Miscellaneous
Vertical Interval
Switching
Line 10/525 line standards; Line 6/625 line standards
Control Interfaces RS422 or RS232 25-pin female "D" connector
