2-56

Section 2 —

Installation

Controlled Destinations Offset

Segments 4, 5, and 6 of switch S1 determine destination offset. The
segments operate in binary fashion (4 most significant; 6 least) to
select destination offsets from 0 to 7. When a destination offset of
0 is selected, the panel controls destination 1. If a destination offset
of 1 is selected, the panel controls destination 11. This sequence
continues through a destination offset of 7 and a destination of 71.

The following table lists switch settings and the resulting
destination offset. An “O” indicates an

open

segment; a “C”

indicates a

closed

segment.

Table 2-13. Remote Panel Destination Offset

Destination

#4

#5

#6

1

O

O

O

11

O

O

C

21

O

C

O

31

O

C

C

41

C

O

O

51

C

O

C

61

C

C

O

71

C

C

C
