2-1
Installation 2
Introduction
This section provides installation information for Performer TM
10 x 1 Routing Switcher. Included here are:
■ Installation Overview
■ Common Configurations
■ Installation Reference
Installation Overview
This section provides step-by-step installation instructions for the
Performer™ in the following order:
■ Uncrating Unpacking and inspecting the
equipment.
■ Button Labeling Installing supplied source names
under front panel button caps.
■ Rack Mounting Installing frame in an equipment rack.
■ Bit-Rate Selection Selecting correct in/out bit-rates via
front panel bit-rate mode switch.
■ Cabling Making cable connections to frame.
■ Power-Up Applying AC power and running a
brief switcher operating check.
NOTE: Factory default settings allow a single system (frame
including local control panel) and a single remote panel to be
connected and used without following all the procedures
necessary for more complicated installations.
