Replacement, Replacement -31, Caution – Grass Valley Performer SD User Manual
Page 63: Installation reference, Front lip
2-31
Installation Reference
Replacement
Wait until all configuration changes are complete. Then replace
the top in reverse order from its removal. Performer setups are
discussed on the following pages.
When replacing the top, make sure you slide the lip into the front
panel slot.
CAUTION
If the top is not replaced exactly according to instructions, it will
no longer be EMI tight.
PERFORMER
–SD
VAA
GRASS
VALLE
Y GROUP
GRASS
VALLE
Y GROUP
INPUT SELECTION
STATUS
DISPLA
Y
360Mb
270Mb
177Mb
143Mb
AUTO
DIRECT
V
A1 CH1/2
A2 CH3/4
Front Lip
