Overview of the controls
3
4
5
4
6
7
1
2 2
Fig. 34: Control elements of the Smart-Control
1: SD-card
2: Movement indicator
3: Display
4: Softkeys
5: Rotary knob
6: Info key
7: Menu key
Function of the keys
The softkeys underneath the display fulfil different
functions. The current function (e.g. Cancel, OK or
Edit) appears on the display, right above the
respective key. If nothing is shown on the display
above a softkey, this key does not have a function
assigned in the currently active mode.
The softkeys and rotary knob are also used for
navigation purposes. By pressing the right softkey
and turning the rotary knob, you can select the
menu items, allowing you to go deeper into the
menu structure. Pressing the left softkey multiple
times takes you back to the home screen (3D
house icon).
Pressing the Info key (6) delivers information and
support at any time on the area currently selected.
Pressing the Menu key (7) takes you to the main
menu.
The rotary knob (5) allows you move through the
menu. In addition, after selecting a parameter, the
rotary knob can be used to modify the value.
5
6
7
Fig. 35: Function of the keys
Additional information on the functional and opera-
tion, refer to the Smart-Control manual.
