Configuration
2013-08-14
109
5.6.3 Deleting Flex-Port Extender Units
Deleting Flex-Port extender units connected to the matrix is not possible.
5.6.4 Deleting Fixed Port Extender Units
In order to delete a fixed port extender unit (e. g. USB 2.0), proceed as
follows:
1. Verify that the fixed port extender unit to be deleted is currently not
assigned to a device.
2. Select the fixed port extender unit to be deleted in the selection list on
the left side of the menu EXT Units and confirm with the key .
3. Press the button Delete.
4. Confirm the delete process with the button Okay.
In order to make a fixed port available again for Flex-Port extender units
after deleting a fixed port extender unit, a restart of the I/O board is
obligatory.
