MDE-4506A Atlas™ Pulser Kits M06245K0XX Installation · May 2006 Page 7
Installing the Pulser Kit in Twin Units (Kits M06245K001 through M06245K003 and M06245K008)
Installing the Pulser Kit in Twin Units (Kits M06245K001
through M06245K003 and M06245K008)
Preparation
1 Request permission from the manager/owner to remove power from the unit and then remove
power using normal procedures. Observe the lockout/tagout safety procedures.
2 Using the proper key for the unit, unlock and remove the doors from both sides of the unit.
Place the doors in a safe place to prevent damage or scratches.
3 On both sides of the unit, remove the two screws securing the bezel and remove the bezel.
Store the bezels and screws in a safe place for reuse.
4 Remove the screws securing the dial face in place and remove the dial faces from each of the
computers on both sides. Store the dial faces and screws in a safe place to prevent damage or
scratches.
5 Ensure that you have the proper kit for the model dispenser to be retrofitted.
Temporarily Moving the Computers
The computers will have to be temporarily moved to allow space between the units to install
the pulser parts. To move the computers, proceed as follows:
1 Note that there are two drive shafts connected to the computer. Make a note of the exact
position of the shafts. Things to note are:
• Bottom (vertical) shaft is set in a slot on the lower end. The pins on the shaft are in the
shallower slots.
• The side shaft is pinned to the drive shaft in the computer and the mark on the rotating
wheel (on the computer) has a mark on it. The mark must be pointing up when
reassembled to properly align the readout number register.
2 Remove the pin from the side (horizontal) shaft mounted to the computer. Save the pin for
reassembly.
3 Loosen and remove the three mounting bolts securing the computer in place. Save for
remounting.
4 Move the computer to allow adequate space for mounting the pulser parts (out of the dispenser
if necessary). Care must be taken to ensure that the large gear on the side of the computer is
kept in the same "OFF" position.
5 Repeat the procedure for the second computer.
