Comtech EF Data CDM-570/L Vipersat Parameter Editor - Manual (Page 76)

Admin
2-60 CDM-570/L, CDD-56X Parameter Editor User Guide
Server IP Address
Enter the mail server address from where email is to be sent.
Domain
Enter the domain of the email server (usually found to the right of the @ symbol
in an email address).
Destination Name
Set the email recipient name (typically found to the left of the @ symbol in an
email address).
Compression
Note: If the Compression feature (FAST code) has not been purchased for this
modem/router, the Compression menu item will not be displayed.
The Compression dialog, shown in figure 2-42, sets the parameters for header
and payload compression in the modem.
This feature only applies to units that have modulators. The parameters are not
applicable to CDD-56X units or to Expansion units, since all demodulators will
automatically detect compressed packets that are received and perform decom-
pression.
Tx Header Compression
If the Enable check box is selected, this modem will transmit packets with
compressed headers.
Note: When compression is enabled, the modem/router checks the HDLC
header to determine whether a received packet has a compressed
header. It is possible, for example, to have header compression enabled
only on some of the modems in a single STDMA group.
The first check box, for L3/L4/L5 (IP, UDP, TCP, and RTP traffic) header
compression, is always set to Enabled and appears grayed out (inactive). This
compression is configured on a per route basis, as described in the section
“Routing” on page 2-7.
