Chapter 2 - Using Parameter Editor 2-9
Network
box becomes inactive and the Next Hop table entry (figure 2-5) will show as
NONE.
Network Address
Enter the destination network IP address for this route to be added to the Viper-
sat unit’s routing table.
Subnet Bits
Enter the number of subnet bits associated with the network address.
HDLC Address
This parameter is not supported in Vipersat networks. Refer to the modem’s
user documentation for additional information.
Next Hop Address
The Next Hop Address box allows entering the IP address of the next hop for a
route which has an Ethernet destination port selected. This address must be on
the local subnet.
Multicast
If the first three digits entered in the Network Address box are in the range of
224 to 239, the address will be recognized as multicast, as shown in figure 2-7.
The Multicast box will become active, allowing the selection of Satellite to
LAN, LAN to Satellite, or both.
Figure 2-7 Multicast Network Address
