Chapter 1 - General 1-3
Product Description
Product Description
Introduction
The Parameter (Param) Editor provides a simple graphical user interface (GUI)
for making configuration changes to modem/routers used in a Vipersat satellite
network. Accessible from both the VMS and VLoad, the Parameter Editor oper-
ates on the param files that store the operating parameters for network terminals.
This user guide documents the Parameter Editor as it applies to the CDM-570/
570L modem and the CDD-56X series of demodulators.
The Parameter Editor is the same in both the VMS and VLoad. However, the
way edited parameters are applied to the Vipersat network modem/routers
differs between the two. Once a modem’s configuration has been changed using
the VMS, the change is immediately applied to the modem. In contrast, changes
made using the VLoad utility are not applied until the new param file is Put
(uploaded) to the unit by the operator.
Note: Many of the parameters will interact with other parameters. Carefully
read the instructions before making changes to a unit’s configuration
settings.
Parameter modifications may also be made directly to the modem/router using
either a direct console connection or a Telnet connection. Refer to the modem/
router’s documentation for details on making equipment parameter modifica-
tions directly at the unit.
For more information on using the Parameter Editor with the VMS, refer to the
Vipersat Management System User Guide.
For more information on using the Parameter Editor with VLoad, refer to the
Vipersat Load Utility User Guide.
Parameter Editor Features
The Parameter Editor software has the following features:
• Simple yet comprehensive graphical user interface.
• Integrated with both the VMS and VLoad.
• Context sensitive for device type as well as for unit role (Hub/Remote).
• Functions with multiple .dll files.
NOTE
