Chapter
2 -
Using Parameter Editor
2-43
Vipersat
Channel Table Signaling Detection
This feature is no longer supported.
ToS Switching
Select the Type of Service switch detection check box to enable the ToS detec-
tion function for this unit.
Applying a ToS value to an application (VoIP, IPVC, or priority data) through
either preservation or classification packet stamping, allows the Vipersat
switching system to function in an encrypted network.
Note: In addition to setting the CDM-570/570L to recognize ToS enabled traf-
fic, the ToS switch type must be included in the subnet or global policy
statement in order for the VMS to act on the switch request.
To configure the ToS switching parameters, click the ToS List menu item
below Application.
Figure 2-29 Type of Service Switching List
Clicking the Add button displays the Type of Service Entry dialog shown in
NOTE
