User Interfaces DMD2401/DMD2401L/DMD2401 IBS/IDR Satellite Modem
4-60 TM065 – Rev. 3.3
<24>
<1>
<1>
<1>
<1>
<1>
<1>
<1>
<1>
<1>
<1>
Tx Circuit ID
Tx Terrestrial
Loopback
Tx Baseband
Loopback
Reserved
Reserved
Data Invert
Framing
Async Baud Rate
Async Port Type
Async Terrestrial
Interface Type
Multiprotocol
Interface Card
Interface Type
Bit 6 = RAM/ROM Fault
Bit 7 = Spare
(0 = Mask, 1 = Allow)
ASCII Characters
0 = Disabled, 1 = Enabled
0 = Disabled, 1 = Enabled
Set to Zero
Set to Zero
0 = Normal, 1 = Invert
Note: The following byte applies only if an
Asynchronous, IDR or IBS Interface is installed. If not, set
to zero.
0 = No Framing, 1 = 1/16 IBS, 2 = 1/16 Async, 3 = 96 Kbit IDR
Note: The following byte applies only if an Asynchronous
Interface Card is installed. If not, set to zero.
0 = 1200
1 = 2400
2 = 4800
3 = 9600
4 = 19200
5 = 50
6 = 110
7 = 300
8 = 600
Note: The following byte applies only if an Asynchronous
Interface Card is installed. If not, set to zero.
0 = RS-232, 1 = RS-485
Note: The following byte applies only if an Asynchronous
Interface Card is installed. If not, set to zero.
0 = V.35, 1 = RS-422, 2 = RS-232
Note: The following byte applies only if a Synchronous
Multiprotocol interface card is installed. If not, set to zero.
0 = V.35,1 = RS-422, 2 = RS-232
Note: The following byte applies only if a symmetric
G.703 interface card is installed. If not, set to zero.
