User Interfaces DMD2401/DMD2401L/DMD2401 IBS/IDR Satellite Modem
4-70 TM065 – Rev. 3.3
<1>
<24>
<1>
<1>
<1>
<1>
<1>
<1>
<1>
<1>
<1>
<1>
BER Measure
Period
Rx Circuit ID
Rx Terrestrial
Loopback
Rx Baseband
Loopback
Rx IF Loopback
Reserved
Data Invert
Async Framing
Async Baud Rate
Async Port Type
Async Terrestrial
Interface Type
Multiprotocol
Interface Card
Interface Type
Unsigned Binary Number of Bits in Measurement Period, in
Powers of Ten (ex: 6 = 10
6
Bits)
24 ASCII Characters
0 = Disabled, 1 = Enabled
0 = Disabled, 1 = Enabled
0 = Disabled, 1 = Enabled
Ignore
0 = Normal, 1 = Invert
Note: The following byte applies only if an
Asynchronous, IDR or IBS Interface is installed. If not,
ignore.
0 = No Framing, 1 = 1/16 IBS, 2 = 1/16 Async, 3 = 96 Kbit IDR
Note: The following byte applies only if an asynchronous
interface card is installed. If not, ignore.
0 = 1200
1 = 2400
2 = 4800
3 = 9600
4 = 19200
5 = 50
6 = 110
7 = 300
8 = 600
Note: The following byte applies only if an asynchronous
interface card is installed. If not, ignore.
0 = RS-232, 1 = RS-485
Note: The following byte applies only if an asynchronous
interface card is installed. If not, ignore.
0 = RS-422, 1 = V.35, 2 = RS-232
Note: The following byte applies only if a synchronous
multiprotocol interface card is installed. If not, ignore.
0 = V.35, 1 = RS-422, 2 = RS-232
Note: The following byte applies only if a symmetric
G.703 interface card is installed. If not, ignore.
