DMD2401/DMD2401L/DMD2401 IBS/IDR Satellite Modem

User Interfaces

TM065 - Rev. 3.3

4-67

Opcode: <2626h>

Command a Modulator’s Async Terrestrial Interface Type

Note: Command <2626h> is only valid if an asynchronous interface card is installed. If
not, this command is ignored. Note: The following command will also turn the carrier off
to protect the satellite.

Mod Async Terr Interface Type

<1>



<1>









<1>

<1>

Async Framing



Async Baud Rate









Async Port Type

Async Terr Intf
Type

0 = No Framing, Async Off
1 = IBS Framing, Async On
2 = IBS Framing, Async Off

0 = 1200
1 = 2400
2 = 4800
3 = 9600
4 = 19200
5 = 50
6 = 110
7 = 300
8 = 600

0 = RS-232, 1 = RS-485

0 = V.35, 1 = RS-422, 2 = RS-232


Opcode: <2631h>

Command a Modulator’s CTS Mode and Polarity

<1>

CTS Control

Bit 0 = Polarity

0 = Normal, 1 = Inverted

Bits 1 and 2 = Mode

0 = Always On (factory default)

1 = CTS reflects the state of the RTS Input

2 = CTS reflects CTS Level Remote Command

Bit 3 - 7 = Spares


Opcode: <2632h>

Command a Modulator’s CTS Level

Query Response

<1>

CTS Level

Bit 0 = Level

0 = Off, 1 = On – only valid if CTS Control Mode bits
are equal to “2”

Bits 1 - 7 = Spares


Opcode: <2637h>

Command a Module’s Carrier Delay

<1>

Carrier Delay

Unsigned Binary Value in seconds (0 - 255)

4.4.13.2 DMD2401 Demodulator


Opcode: <2401h>

Query a Modulator’s Configuration and Status

Query Response

<1>

Number of

Nonvol bytes

See Paragraph B.6. This is the number of configuration

bytes and is an offset to the start of the status block.
