DMD2401/DMD2401L/DMD2401 IBS/IDR Satellite Modem

User Interfaces

TM065 - Rev. 3.3

4-63









<1>











<1>











<1>

































IDR Force
Backward Alarm
2









IDR Force
Backward Alarm
3









IDR Force
Backward Alarm
4









Interface Type











Note: The following byte applies only if an IDR OR IBS
interface card is installed, and the transmit mode
parameter is set to IDR Mode. If an IDR OR IBS interface
card is not installed, set to zero. If an IDR OR IBS
interface card is installed, but the transmit mode
parameter is not set to IDR mode, these bytes can be set
to any valid values, but will be ignored.



0 = Force Alarm Always ON
1 = Force Alarm Always OFF
2 = Normal Operation

Note: The following byte applies only if an IDR OR IBS
interface card is installed, and the transmit mode
parameter is set to IDR Mode. If an IDR OR IBS interface
card is not installed, set to zero. If an IDR OR IBS
interface card is installed, but the transmit mode
parameter is not set to IDR mode, these bytes can be set
to any valid values, but will be ignored.

0 = Force Alarm Always ON
1 = Force Alarm Always OFF
2 = Normal Operation

Note: The following byte applies only if an IDR OR IBS
interface card is installed, and the transmit mode
parameter is set to IDR Mode. If an IDR OR IBS interface
card is not installed, set to zero. If an IDR OR IBS
interface card is installed, but the transmit mode
parameter is not set to IDR mode, these bytes can be set
to any valid values, but will be ignored.

0 = Force Alarm Always ON
1 = Force Alarm Always OFF
2 = Normal Operation

Note: The following byte applies only if an IDR OR IBS
interface card is installed, and the transmit mode
parameter is set to IDR Mode. If an IDR OR IBS interface
card is not installed, set to zero. If an IDR OR IBS
interface card is installed, but the transmit mode
parameter is not set to IDR mode, these bytes can be set
to any valid values, but will be ignored.

If G.703 daughter card is installed:

0 = G.703 Unbalanced E1
1 = G.703 Balanced E1
2 = G.703 T1, B8ZS

If Synchronous multiprotocol daughter card is installed:

0 = V.35
1 = RS-422
2 = RS-232

Note: The following two bytes apply only if an IDR OR IBS
