Comtech EF Data DMD2401/DMD2401L - Manual (Page 89)

User Interfaces DMD2401/DMD2401L/DMD2401 IBS/IDR Satellite Modem
4-50 TM065 – Rev. 3.3
<1>
<1>
<1>
<1>
<1>
<1>
<1>
<2>
<2>
<2>
<2>
Async Baud Rate
Async Port Type
Async Terrestrial
Interface Type
Multiprotocol
Interface Card
Interface Type
G.703 Interface
Type
BPSK Symbol
Pairing
AUPC Enable
AUPC Eb/No
AUPC Minimum
Power Limit
AUPC Maximum
Power Limit
AUPC Default
Power Level
0 = 1200
1 = 2400
2 = 4800
3 = 9600
4 = 19200
5 = 50
6 = 110
7 = 300
8 = 600
0 = RS-232, 1 = RS-485
0 = V.35, 1 = RS-422, 2 = RS-232
Note: The following byte applies only if a Synchronous
Multiprotocol Interface Card is installed. If not, ignore.
0 = RS-422, 1 = V.35, 2 = RS-232
Note: The following byte applies only if a Symmetric
G.703 Interface Card is installed. If not, ignore.
0 = G703T1AMI
1 = G703T1B8ZS
2 = G703BE1
3 = G703UE1
Note: The following byte applies to all DMD2401 modems,
regardless of interface type.
0 = Normal, 1 = Swapped
Note: The following nine bytes apply only if an
Asynchronous Interface Card or IBS Interface Card is
installed, and the AUPC option is also installed. If not, set
to zero.
Note: AUPC minimum power level < AUPC default power
level < AUPC max. power level.
0 = Disabled, 1 = Enabled
Unsigned Binary (1 Decimal Point Implied)
Signed Value, –50 to –300 (–5.0 to –30 dBm), Implied Decimal
Point
Signed Value, –50 to –300 (–5.0 to –30 dBm), Implied Decimal
Point
Signed Value, –50 to –300 (–5.0 to –30 dBm), Implied Decimal
Point
Note: The following two bytes apply only if an IDR or IBS
