User Interfaces DMD2401/DMD2401L/DMD2401 IBS/IDR Satellite Modem
4-98 TM065 – Rev. 3.3
<1> BER Measure
Period 10
5
Bits <05>
<24> Rx Circuit ID 24 ASCII Spaces <20> <20> <20> <20> <20>
<20> <20> <20> <20> <20>
<20> <20> <20> <20> <20>
<20> <20> <20> <20> <20>
<20> <20> <20> <20>
<1> Rx Terrestrial
Loopback 0 = Disabled <00>
<1> Rx Baseband
Loopback 0 = Disabled <00>
<1> Rx IF Loopback 0 = Disabled <00>
<1> CD/Clock Control 0 = Receiver Allows Output
Clock When CD False
<00>
<1> Data Invert 0 = Normal <00>
<1> Async Mode 0 = Async Off <00>
<1> Async Baud Rate 3 = 9600 <03>
<1> Async Port Type 0 = RS-232 <00>
<1> Async Terrestrial
Interface Type RS-422 <00>
<1> Multiprotocol
Interface Type 0 = RS-422 <00>
<1> G.703 Interface
Type 0 = G703T1AMI <00>
<1> BPSK Symbol
Pairing 0 = Normal <00>
<1> Receive Mode 0 = Closed Net <00>
<1> T1/E1 Frame
Source 0 = Internal <00 >
<1> Receive IDR
Overhead Mode 0 = Voice <00>
<1> Receive IDR
Backward Alarm
Mask No Alarms Masked
<1> Interface Type <00>
<2> Receive ESC #1
Volume -20 dB
<2> Receive ESC #2
Volume -20 dB
<1> Alarm 5 Mask No Alarms Masked
