DMD2401/DMD2401L/DMD2401 IBS/IDR Satellite Modem User Interfaces
TM065 - Rev. 3.3 4-65
Encoder
Opcode: <2609h>
Command a Modulator’s Carrier Control
<1> Carrier Control 0 = Off, 1 = On, 2 = Auto, 3 = VSat, 4 = RTS
Opcode: <260Ah>
Command a Modulator’s Carrier Selection
<1> Carrier Selection 0 = Normal, 1 = CW, 2 = Dual, 3 = Offset
Opcode: <260Bh>
Command a Modulator’s Clock Control
<1> Clock Control 0 = Internal (SCT), 1 = External (SCTE)
Opcode: <260Ch>
Command a Modulator’s Clock Polarity
<1> Clock Polarity 0 = Normal, 1 = Inverted, 2 = Auto
Opcode: <260Dh>
Command a Modulator’s SCT Source
<1> SCT Source 0 = Internal, 1 = SCR, 2 = Ext. BNC
Opcode: <260Eh>
Command a Modulator’s Drop Mode
<1> Mode 0 = Disable
1 = T1-D4
2 = T1-ESF
3 = PCM-30
4 = PCM-30C
5 = PCM-31
6 = PCM-31C
7 = T1-SLC96
Opcode: <260Fh>
Command a Modulator’s Output Level
<2> Transmit Power
Level Signed Binary Value. -50 to -300 (-5.0 to -30.0 dBm), Implied
Decimal Point
