User Interfaces DMD2401/DMD2401L/DMD2401 IBS/IDR Satellite Modem
4-78 TM065 – Rev. 3.3
<1>
<1>
<1>
<1>
<1>
<1>
<1>
<1>
<1>
<1>
BER/EbNo Status
Buffer Percent
Full
Input Level
Input Level State
Alarm 5
Backward Alarms
Latched Alarm 5
Control Mode
Alarm 5
Insert Alarms
Bit 0 = Raw BER and Corrected BER Status (1 = Valid)
Bit 1 = Test 2047 BER Status (1 = Valid)
Bits 2 - 3 = EbNo Status (0 = EbNo is Invalid, 1 = EbNo is
Valid, 2 = EbNo is Smaller Than Indicated Value, 3 =
EbNo is Greater Than Indicated Value)
Bits 4 - 7 = Reserved
Unsigned Binary Value Representing % Buffer Full (0 - 100 in
1% steps)
Unsigned Binary Value in -1 dB Steps, Negative Sign Implied
Signed Binary (0 = Equal to, 1 = Greater Than, -1 = Less Than
Value in -1 dB Steps, Negative Sign Implied)
Bit 0 = IBS/IDR Satellite Multiframe Sync Loss
Bit 1 = IBS/IDR Satellite Frame Sync Loss
Bit 2 = Spare
Bit 3 = IBS BER Alarm
Bit 3 = IBS Prompt Alarm
Bit 5 = IBS Service Alarm
Bits 6 - 7 = Spares
(0 = Pass, 1 = Fail)
Bit 0 = IBS Backward Alarm or IDR Backward Alarm 1
Bit 1 = IDR Backward Alarm 2
Bit 2 = IDR Backward Alarm 3
Bit 3 = IDR Backward Alarm 4
Bits 4 - 7 = Spares
(0 = Pass, 1 = Fail)
Bit 0 = IBS/IDR Satellite Multiframe Sync Loss
Bit 1 = IBS/IDR Satellite Frame Sync Loss
Bit 2 = Spare
Bit 3 = IBS BER Alarm
Bit 4 = IBS Prompt Alarm
Bit 5 = IBS Service Alarm
Bit 6 - 7 = Spares
(0 = Pass, 1 = Fail)
0 = Front Panel, 1 = Terminal, 2 = Computer RLLP
Bit 0 = IBS Satellite Multiframe Loss
Bit 1 = IBS Satellite Frame Loss
Bit 2 = Spare
Bit 3 = IBS Alarm if BER < 10
-03
Bit 4 = IBS Prompt Alarm
Bit 5 = IBS Service Alarm
Bits 6 - 7 = Spares
Bit 0 = Frame Lock Fault
Bit 1 = Multiframe Lock Fault
Bit 2 = CRC Lock Fault. Valid only in T1-ESF and E1 - CRC
enabled
Bit 3 = T1 Yellow Alarm Received
Bit 4 = E1 FAS Alarm Received
Bit 5 = E1 MFAS Alarm Received
Bit 6 = E1 CRC Alarm Received
