A b o u t M e m o r y B u f f e r s
Transmit Buffer
Used to send ENQ, job, and upload
responses. This buffer must be allocated as
volatile (R) RAM.
Receive Buffer
Used to save data received from the host
before it is processed by the printer.
Changing this buffer size affects the amount
of data the printer can receive without using
flow control. This buffer must be allocated as
volatile (R) RAM.
Image Buffer
Used to image the current format. The 9800
printers support two 4-inch by 8-inch buffers.
You can create an image up to 16 inches long
without reallocating memory. The Image
Buffer is cleared after a printer reset, even if
it is stored in non-volatile RAM.
Use the formula below to calculate the
required image buffer size.
19.13K x
Length
Length is the length of your label in inches.
Example
19.13K x 6 = 114.78K
(Multiply by 10 and round up.)
114.78K x 10 = 1147.8
1147.8 = 1150
Enter 1150 for your Image buffer.
2-28 Configuring the Printer
