P R I N T E R D I F F E R E N C E S
E
Here are the major features and differences between each printer.
Earlier printer versions may not support all features.
P r i n t e r C o m p a r i s o n
Feature 9403 Printer 9825 Printer 985x/9860 Printer
Printhead
Density DPI
(dots per inch) 203 DPI 203 DPI 203 DPI
300 DPI (optional)
Print speed IPS
(inches per
second) 2.0 IPS 2.5, 4.0, or 6.0 IPS 2.5, 4.0, 6.0, 8.0, 10.0,
or 12.0 IPS (optional)
9860 max. is 8.0 IPS
Maximum print
area 2.0" x 6.0" 4.0" x 16.0" 4.0" x 16.0"
4.0" x 13.0" (w/300 dpi)
Non-Print Zone .035" at the
beginning and .10"
from the left edge Recommended: all
supplies - .05" on
either edge and .02" at
the end
Butt cut supplies - .15"
at the beginning Recommended: all‘
supplies - .05" on
either edge and .02" at
the end
Butt cut supplies - .15"
at the beginning
Location of Print
Area Left Center Center
Supply Width .75" x 2.5" .75" x 4.25" .75" x 4.25"
Supply Length .75" x 9.0" .50" x 17.5" .32" x 17.5"
Power Up Mode Online/
Offline Online Online/Offline
Feed Mode Continuous On demand/
Continuous/
Peel Mode (optional) On demand/
Continuous/
Peel Mode (optional)
9860 does not support
peel mode
Supplies Tags or Labels Labels or Perforated
Tags Labels or Tags
Supply Type Black mark
Die cut Edge Aperture/
Black mark/Die cut/
Continuous Aperture/
Black mark/Die cut/
Continuous
9860 does not support
continuous supply
Printer Differences E-1
