AL-MEISTER ALM3222 Instruction Manual
Page 35 of 63
5. AUTOMATIC OPERATION (cont’d)
5-2. SETTINGS
5-2-1. SET TEMPERATURE
On the “READY” screen press TEMP./SPEED button once.
* The default is set at 210F. This is only a
power on default and may not be proper for
some paper stocks and thicknesses of film.
Press UP or DOWN button to set temperature. Temperature can be set OFF, and between 170F and
270F in 10F increments. The temperature display blinks.
Press TEMP./SPEED button to confirm the temperature.
This table shows an example of temperature settings for different film and paper thicknesses. It also
pays to experiment with different temperatures and speeds to achieve quality laminations.
Film thickness Copying paper Thicker paper
1.5mil 210F - 40"/min 220F - 40" /min
3mil – 4mil 220F - 40" /min 230F - 40" /min
5mil 230F - 40"/min 240F - 40" /min
