AL-MEISTER ALM3222 Instruction Manual
Page 20 of 63
4. SET LAMINATION FILM/MANUAL MODE
1. AL-ROLL film is the exclusive lamination film for ALM3222. Always use a combined set of upper and lower
film together (even if using one-sided film) from the same box. Prior to loading film inspect the rolls for
possible shipping damage. Lower film roll must have a valid RFID tag installed and loaded towards the non-
operator side of the machine.
ATTENTION: If this tag is not in place or it has been damaged the machine will not heat up, or run in automatic
mode.
Do not install damaged or “shifted (telescoped)” rolls of film on the ALM3222. These rolls may
have been damaged in shipment. The two sheets of film will not overlap each other properly
and will causes operational problems.
2. Open the cover at the trimmer. Adjust both the left and right levers to the FILM SET position. Leave this the
cover open for the next steps.
Always make sure that the levers are at the film set position when threading. Otherwise, the
threading card will get caught on the trimmer blades. Damage to the trimmer blades and
jamming of film may occur.
