Altera Arria V GX FPGA Development Board User Manual
Page 66
2–56
Chapter 2: Board Components
Components and Interfaces
Arria V GX FPGA Development Board
November 2013
Altera Corporation
Reference Manual
Table 2–49
lists the FMC interface component reference and manufacturing
information.
H16
FMC_LA_P11
AL15
2.5-V CMOS
FMC data bus LPC bank A
G15
FMC_LA_P12
AK16
2.5-V CMOS
FMC data bus LPC bank A
D17
FMC_LA_P13
AL14
2.5-V CMOS
FMC data bus LPC bank A
C18
FMC_LA_P14
AU13
2.5-V CMOS
FMC data bus LPC bank A
H19
FMC_LA_P15
AM16
2.5-V CMOS
FMC data bus LPC bank A
G18
FMC_LA_P16
AL24
2.5-V CMOS
FMC data bus LPC bank A
D20
FMC_LA_P17
AP15
2.5-V CMOS
FMC data bus LPC bank A
C22
FMC_LA_P18
AD16
2.5-V CMOS
FMC data bus LPC bank A
H22
FMC_LA_P19
AW22
2.5-V CMOS
FMC data bus LPC bank A
G21
FMC_LA_P20
AT16
2.5-V CMOS
FMC data bus LPC bank A
H25
FMC_LA_P21
AH22
2.5-V CMOS
FMC data bus LPC bank A
G24
FMC_LA_P22
AC22
2.5-V CMOS
FMC data bus LPC bank A
D23
FMC_LA_P23
AW18
2.5-V CMOS
FMC data bus LPC bank A
H28
FMC_LA_P24
AK25
2.5-V CMOS
FMC data bus LPC bank A
G27
FMC_LA_P25
AL23
2.5-V CMOS
FMC data bus LPC bank A
D26
FMC_LA_P26
AL22
2.5-V CMOS
FMC data bus LPC bank A
C26
FMC_LA_P27
AH23
2.5-V CMOS
FMC data bus LPC bank A
H31
FMC_LA_P28
AH24
2.5-V CMOS
FMC data bus LPC bank A
G30
FMC_LA_P29
AP26
2.5-V CMOS
FMC data bus LPC bank A
H34
FMC_LA_P30
AF27
2.5-V CMOS
FMC data bus LPC bank A
G33
FMC_LA_P31
AH27
2.5-V CMOS
FMC data bus LPC bank A
H37
FMC_LA_P32
AD24
2.5-V CMOS
FMC data bus LPC bank A
G36
FMC_LA_P33
AD25
2.5-V CMOS
FMC data bus LPC bank A
F1
FMC_M2C_PG
—
2.5-V CMOS
Power good input
H2
FMC_PRSNT
—
2.5-V CMOS
FMC module present
C30
FMC_SCL
—
2.5-V CMOS
Management serial clock line
C31
FMC_SDA
—
2.5-V CMOS
Management serial data line
Table 2–50. FMC Connector Pin Assignments, Schematic Signal Names, and Functions (Part 7 of 7)
Board
Reference
(J10)
Schematic
Signal Name
Arria V GX
FPGA
Pin Number
I/O Standard
Description
Table 2–51. FMC Connector Component Reference and Manufacturing Information
Board
Reference
Description
Manufacturer
Manufacturing
Part Number
Manufacturer
Website
J10
FMC pitch socket array assembly connector
Samtec
ASP-134486-01
