Chapter 2: Board Components 2–53
Components and Interfaces
November 2013 Altera Corporation Arria V GX FPGA Development Board
Reference Manual
K7 FMC_HA_P2 AV16 2.5-V CMOS FMC data bus HPC bank A
J6 FMC_HA_P3 AP17 2.5-V CMOS FMC data bus HPC bank A
F7 FMC_HA_P4 AK10 2.5-V CMOS FMC data bus HPC bank A
E6 FMC_HA_P5 AL11 2.5-V CMOS FMC data bus HPC bank A
K10 FMC_HA_P6 J8 2.5-V CMOS FMC data bus HPC bank A
J9 FMC_HA_P7 AH14 2.5-V CMOS FMC data bus HPC bank A
F10 FMC_HA_P8 AD19 2.5-V CMOS FMC data bus HPC bank A
E9 FMC_HA_P9 AM7 2.5-V CMOS FMC data bus HPC bank A
K13 FMC_HA_P10 F6 2.5-V CMOS FMC data bus HPC bank A
J12 FMC_HA_P11 AC18 2.5-V CMOS FMC data bus HPC bank A
F13 FMC_HA_P12 AJ18 2.5-V CMOS FMC data bus HPC bank A
E12 FMC_HA_P13 AF19 2.5-V CMOS FMC data bus HPC bank A
J15 FMC_HA_P14 AD14 2.5-V CMOS FMC data bus HPC bank A
F16 FMC_HA_P15 AH20 2.5-V CMOS FMC data bus HPC bank A
E15 FMC_HA_P16 AL17 2.5-V CMOS FMC data bus HPC bank A
K16 FMC_HA_P17 AT25 2.5-V CMOS FMC data bus HPC bank A
J18 FMC_HA_P18 AP20 2.5-V CMOS FMC data bus HPC bank A
F19 FMC_HA_P19 AP19 2.5-V CMOS FMC data bus HPC bank A
E18 FMC_HA_P20 AN21 2.5-V CMOS FMC data bus HPC bank A
K19 FMC_HA_P21 AP23 2.5-V CMOS FMC data bus HPC bank A
J21 FMC_HA_P22 AP22 2.5-V CMOS FMC data bus HPC bank A
K22 FMC_HA_P23 AP24 2.5-V CMOS FMC data bus HPC bank A
K26 FMC_HB_N0 AH13 2.5-V CMOS FMC data bus HPC bank B
J25 FMC_HB_N1 AV12 2.5-V CMOS FMC data bus HPC bank B
F23 FMC_HB_N2 AT11 2.5-V CMOS FMC data bus HPC bank B
E22 FMC_HB_N3 AW10 2.5-V CMOS FMC data bus HPC bank B
F26 FMC_HB_N4 AF13 2.5-V CMOS FMC data bus HPC bank B
E25 FMC_HB_N5 AE14 2.5-V CMOS FMC data bus HPC bank B
K29 FMC_HB_N6 AF12 2.5-V CMOS FMC data bus HPC bank B
J28 FMC_HB_N7 AG11 2.5-V CMOS FMC data bus HPC bank B
F29 FMC_HB_N8 AP10 2.5-V CMOS FMC data bus HPC bank B
E28 FMC_HB_N9 AL10 2.5-V CMOS FMC data bus HPC bank B
K32 FMC_HB_N10 AC13 2.5-V CMOS FMC data bus HPC bank B
J31 FMC_HB_N11 AV9 2.5-V CMOS FMC data bus HPC bank B
F32 FMC_HB_N12 AU10 2.5-V CMOS FMC data bus HPC bank B
E31 FMC_HB_N13 AT9 2.5-V CMOS FMC data bus HPC bank B
K35 FMC_HB_N14 AP13 2.5-V CMOS FMC data bus HPC bank B
J34 FMC_HB_N15 AH12 2.5-V CMOS FMC data bus HPC bank B
Table 2–50. FMC Connector Pin Assignments, Schematic Signal Names, and Functions (Part 4 of 7)
Board
Reference
(J10)
Schematic
Signal Name
Arria V GX
FPGA
Pin Number
I/O Standard Description
