Altera Arria V GX FPGA Development Board User Manual
Page 57
Chapter 2: Board Components
2–47
Components and Interfaces
November 2013
Altera Corporation
Arria V GX FPGA Development Board
Reference Manual
36
HSMB_JTAG_TMS
—
2.5-V CMOS
JTAG mode select signal
37
HSMB_JTAG_TDO
—
2.5-V CMOS
JTAG data output
38
HSMB_JTAG_TDI
—
2.5-V CMOS
JTAG data input
39
HSMB_CLK_OUT0
AJ33
LVDS or 2.5-V Dedicated CMOS clock out
40
HSMB_CLK_IN0
AR6
LVDS or 2.5-V Dedicated CMOS clock in
41
HSMB_D0
AW25
2.5-V CMOS
Dedicated CMOS I/O bit 0
42
HSMB_D1
AW26
2.5-V CMOS
Dedicated CMOS I/O bit 1
43
HSMB_D2
AV25
2.5-V CMOS
Dedicated CMOS I/O bit 2
44
HSMB_D3
AV24
2.5-V CMOS
Dedicated CMOS I/O bit 3
47
HSMB_TX_D_P0
AC29
LVDS or 2.5-V LVDS TX bit 0 or CMOS bit 4
48
HSMB_RX_D_P0
AC25
LVDS or 2.5-V LVDS RX bit 0 or CMOS bit 5
49
HSMB_TX_D_N0
AB29
LVDS or 2.5-V LVDS TX bit 0n or CMOS bit 6
50
HSMB_RX_D_N0
AB25
LVDS or 2.5-V LVDS RX bit 0n or CMOS bit 7
53
HSMB_TX_D_P1
AE28
LVDS or 2.5-V LVDS TX bit 1 or CMOS bit 8
54
HSMB_RX_D_P1
AF25
LVDS or 2.5-V LVDS RX bit 1 or CMOS bit 9
55
HSMB_TX_D_N1
AD28
LVDS or 2.5-V LVDS TX bit 1n or CMOS bit 10
56
HSMB_RX_D_N1
AE25
LVDS or 2.5-V LVDS RX bit 1n or CMOS bit 11
59
HSMB_TX_D_P2
AE29
LVDS or 2.5-V LVDS TX bit 2 or CMOS bit 12
60
HSMB_RX_D_P2
AD27
LVDS or 2.5-V LVDS RX bit 2 or CMOS bit 13
61
HSMB_TX_D_N2
AD29
LVDS or 2.5-V LVDS TX bit 2n or CMOS bit 14
62
HSMB_RX_D_N2
AC27
LVDS or 2.5-V LVDS RX bit 2n or CMOS bit 15
65
HSMB_TX_D_P3
AK27
LVDS or 2.5-V LVDS TX bit 3 or CMOS bit 16
66
HSMB_RX_D_P3
AB28
LVDS or 2.5-V LVDS RX bit 3 or CMOS bit 17
67
HSMB_TX_D_N3
AJ27
LVDS or 2.5-V LVDS TX bit 3n or CMOS bit 18
68
HSMB_RX_D_N3
AB27
LVDS or 2.5-V LVDS RX bit 3n or CMOS bit 19
71
HSMB_TX_D_P4
AL29
LVDS or 2.5-V LVDS TX bit 4 or CMOS bit 20
72
HSMB_RX_D_P4
AJ28
LVDS or 2.5-V LVDS RX bit 4 or CMOS bit 21
73
HSMB_TX_D_N4
AK29
LVDS or 2.5-V LVDS TX bit 4n or CMOS bit 22
74
HSMB_RX_D_N4
AH28
LVDS or 2.5-V LVDS RX bit 4n or CMOS bit 23
77
HSMB_TX_D_P5
AL30
LVDS or 2.5-V LVDS TX bit 5 or CMOS bit 24
78
HSMB_RX_D_P5
AG28
LVDS or 2.5-V LVDS RX bit 5 or CMOS bit 25
79
HSMB_TX_D_N5
AK30
LVDS or 2.5-V LVDS TX bit 5n or CMOS bit 26
80
HSMB_RX_D_N5
AF28
LVDS or 2.5-V LVDS RX bit 5n or CMOS bit 27
83
HSMB_TX_D_P6
AL32
LVDS or 2.5-V LVDS TX bit 6 or CMOS bit 28
84
HSMB_RX_D_P6
AH30
LVDS or 2.5-V LVDS RX bit 6 or CMOS bit 29
85
HSMB_TX_D_N6
AK32
LVDS or 2.5-V LVDS TX bit 6n or CMOS bit 30
86
HSMB_RX_D_N6
AG30
LVDS or 2.5-V LVDS RX bit 6n or CMOS bit 31
89
HSMB_TX_D_P7
AM31
LVDS or 2.5-V LVDS TX bit 7 or CMOS bit 32
Table 2–46. HSMC Port B Pin Assignments, Schematic Signal Names, and Functions (Part 2 of 4)
Board
Reference (J2)
Schematic Signal Name
Arria V GX
FPGA
Pin Number
I/O Standard
Description
