9 CHANNEL 2.4GHz AIRCRAFT COMPUTER RADIO SYSTEM
To the heli owner using this manual for the first time it is recommended you proceed through the following material
contained in this manual:
1. Section one introductory information
2. Section three, the heli quick start guide
3. Section four, the system menu
4. Section five, common features of all model types
After setting the heli up in the Aurora 9X system menu through the MDL. Sel. feature as described in section two, visit
section five for all the basic set-up functions, then skip back to this section for the rest of the information.
{— {—
Tip
The Aurora 9X offers a rich selection of features to fly everything from the simplest to very complex and
sophisticated helis.
The following Aurora 9X features are specific to heli aircraft:
Flight Conditions Flight conditions or Idle-Up menu
P. Curve & T. Curve Rotor blade pitch curve and Throttle curve adjustment
SWH->THR Swash plate movement to throttle mix
RUD->THR Tail rotor to throttle mix
T. HOLD Throttle hold function
SwashMix Swash plate fine tuning menu
REVO Mix Revolution mix
Gyro Gyro sensitivity control menu
Governor RPM governor adjustment
These additional set-up functions are defined earlier in the manual.
EPA End Point Adjustment
D/R & EXP Dual Rates and Exponential (expo) rates
Sub-Trim Servo Sub-trim adjustment
Reverse Servo reversing function
S. Speed Servo Speed feature
Monitor Active model control monitor
P. Mixs Programmable Mixing
Model Menu - HELI Specific Functions
S
ec
tion S
e
ven
126
