HITEC Aurora 9X - Manual (Page 10)

9 CHANNEL 2.4GHz AIRCRAFT COMPUTER RADIO SYSTEM
Icon Identification
Icon Identification
MODEL The model menu contains the model programming for the active model.
ACRO Menu for fixed wing, glow, gas and some electric models.
GLID Menu for gliders and some electric models.
HELI Menu for rotary wing aircraft.
EXIT DOOR Appears in the upper right corner, the “go back” icon.
FOLDER The custom menu. Often used, or “quick access” feature folder.
WRENCH The system menu contains model set-up and transmitter feature menus.
ADJUST The adjustment menu contains the adjustment features for quick access.
AILE Aileron for fixed wing menus and the “roll” swash input for helis.
ELEV Elevator for fixed wing menus and the “pitch” swash input for helis.
RUDD Rudder for fixed wing menus and the “yaw”, or tail rotor input for helis.
1/2, 1/3, 1/6 FRACTIONS Indicates the number of pages in the menu. Press to access the next page.
+ RST – Often used Aurora menu value input icons. Value adjustment icon + /–, RST : Reset
Arrow Press to cycle through menu options.
C Combination icon. Flight mode option, “groups” the flight mode values.
S Separate icon. Flight mode option, “separates” the flight mode value.
INH Inhibit is used to “turn off” a function.
SEL Select is used to “select” a feature of the displayed menu.
ACT Active, “turns on” a function.
NULL “No switch” selected, the function or feature will be “on” all the time.
AUX An “open” channel, without a control assigned to it.
J1 Right gimbal, up and down control.
J2 Right gimbal, side to side control
J3 Left gimbal, up and down control.
J4 Left gimbal side to side control.
T1 J1 control trim.
T2 J2 control trim.
T3 J3 control trim.
T4 J4 control trim.
LT Left VR switch.
CT Center VR switch.
RT Right VR switch.
RS Right slider control.
LS Left slider control.
Multi-I/O File sharing, trainer and PC interface mode.
DataTran User can up / down load model setup data thru a PC.
T.Pupil Aurora in pupil, or training mode.
