HITEC Aurora 9X - Manual (Page 118)

9 CHANNEL 2.4GHz AIRCRAFT COMPUTER RADIO SYSTEM
118
B-fly (GLID)
We suggest you choose the throttle, THR . as the “switch” activating the mix. This gives a linear,
progressive deployment and retraction of the flight control surfaces.
{— {—
Tip
a. Select B-Fly from the model menu.
b. Press ACT to activate the
Butterfly control feature menu.
Butterfly or Crow Mix.
Butterfly, also known as “Crow” mixing is used to land slippery gliders easier and with greater accuracy.
The mix is usually activated with the linear action of the throttle stick which drops the flaps, raises the ailerons and
employs a bit of up elevator to compensate for the pitch down created by all the additional control surface drag.
### This function can be influenced by the flight condition feature ###
Switch Option
c. Select a 2 position switch and/or the throttle stick to activate the butterfly mix. Choose a “cut” point if you wish,
and apply an in flight adjustment switch by pressing
NULL and following the switch activation process.
d. Use the +RST- icon to set a movement value for
the aileron, elevator and flaps. Move the throttle
stick to see the effect of the movement values
you selected for the flight control surfaces.
e. Select the Exit icon to return to the model menu.
Switch type Function Cut Function VR adjustment
2 position Variable function Cut control choice Fine tuning control choice
and/or throttle
