48
MANUAL STOP – S48
Active program: 03
Stop program: -- ?
PROG MAN STOP S48
Each program can be manually stopped using this panel. This panel displays
and allows the setting of the following parameters:
− Active program -
Active program - Active program - Active program - Active program - The currently active program.
− Stop program Stop program Stop program Stop program Stop program - The program selected for deactivation. User selectable.
CONTROLLER STATE – S49
STOP - WORK
WORK -
INIT -
CONTROLLER STATE S49
This panel allows manual manipulation of the controller state. Once entering
the set mode, one of the 3 conditions can be selected using the arrow keys. Y
(yes) can be entered next to the selected condition to change the controller
state. Only the Y (yes) key will have effect in activating the appropriate state.
This panel displays and allows the setting of the following parameters:
− Current controller status
Current controller status Current controller status Current controller status Current controller status – see top right corner
− ST ST ST ST STOP OP OP OP OP - Enter Y (yes) then ENTER ENTER ENTER ENTER ENTER to place controller in stop state.
− WORK WORK WORK WORK WORK - Enter Y (yes) then ENTER ENTER ENTER ENTER ENTER to place controller in work state. If
certain alarm conditions exist it is not possible to enter WORK state.
− INIT INIT INIT INIT INIT - Enter Y (yes) then ENTER ENTER ENTER ENTER ENTER to place controller in initialization state
(reset the controller).
OUTLET MAN CTRL – S50
Number: 27
Opened: Y
Value: -
OUTLET MAN CTRL S50
In this panel the outlet number is used as the index. See in Appendixes the
outlet assignment. This panel displays and allows the setting of the following
parameters:
− Number -
Number - Number - Number - Number - Panel index. Outlet number.
− Opened Opened Opened Opened Opened -The status of the indexed outlet.
− VVVVValue alue alue alue alue -Enter Y (yes) or N (no) to open or close the indexed outlet.
