40
− W W W W Weekday eekday eekday eekday eekday - Weekday labels
− W W W W Workday orkday orkday orkday orkday - Use yes or no indication (on keypad) below each weekday label
to indicate specific workdays for the indexed program.
SET PRIORITY – S31
Prog 07
Priority 04
Sector/Group 08
SET PRIORITY S31
This panel allows the setting of priority level for each program. Programs can
share the same priority level. When a conflict occurs between two programs
with the same priority, the program with the earliest starting time will execute
first. The program number indexes this panel. This panel displays and allows
the setting of the following parameters:
− P
P P P Program Number rogram Number rogram Number rogram Number rogram Number - Panel index (used to view settings for all programs).
− Priority Priority Priority Priority Priority - The priority level. This number can be set from 1 to 6 with 6 being
the highest priority.
− Sectors / Group Sectors / Group Sectors / Group Sectors / Group Sectors / Group - The maximum number of sectors that can be open in
the same time by the indexed program.
START CONDITIONS – S32
Time cond:Y Prog 07
Link 02
Ext Tank: Y
START CONDITIONS S32
How a particular program is triggered (started) can be selected with the use of
this panel. Multiple start conditions can be chosen for a program
Multiple start conditions can be chosen for a program Multiple start conditions can be chosen for a program Multiple start conditions can be chosen for a program Multiple start conditions can be chosen for a program
in the same time. in the same time. in the same time. in the same time. in the same time. By this panel a program can be set to activate at a
certain time, by the level of the external tank, or directly after the completion of
another program. The program number indexes this panel. This panel dis-
plays and allows the setting of the following parameters:
− Time cond
Time cond Time cond Time cond Time cond - Time condition start. On keypad select Y for yes or N for no.
− PPPPProgram Number rogram Number rogram Number rogram Number rogram Number - Panel index (used to view settings for all programs).
− Ext tank - Ext tank - Ext tank - Ext tank - Ext tank - By selecting external tank trigger, the start of the program is
based on the level of the external tank.
− Link Link Link Link Link - By selecting Link and entering a master program number, the start of
the selected program directly follows (linked to) the completion of its mas-
ter program.
