This panel displays the state of the agitator for the current selected program.
The agitators can be activated before dosing of a fertilizer, during dosing, or
intermittently throughout the program. The program number indexes this panel.
This panel contains the following information:
− PPPPProgram Number
rogram Number rogram Number rogram Number rogram Number - Panel index (used to view settings for all programs).
− W W W W Work ork ork ork ork – the set working time for the agitator.
− PPPPPause ause ause ause ause – the set pause time for the agitator.
− − − − − System clock. System clock. System clock. System clock. System clock.
NO NO NO NO NOTE TE TE TE TE::::: For HI8060 the agitators are wired to the fertilizer pump control signal.
PROG LAST START – C16
Prog 08 Filter --
Last start Manual
At 28-08 18:32 13:15
PROG LAST START C16
This panel displays the starting reason and the time moment of the indexed
program’s previous start, including filter-cleaning programs. There are 2 fil-
ter-cleaning programs one for each filter. The filter programs follow the in-
dexed irrigation programs. For example, if the Fertigation Controller is equipped
with 10 irrigation programs, “Prog” number 11 and 12 will be designated for
the two filter cleaning programs on the above panel. In this case the first 10
program numbers will indicate the last start data for the irrigation process and
programs 11 and 12 will indicate the last start data for filter cleaning. The
program number indexes this panel. This panel contains the following infor-
mation:
− PPPPProgram Number
rogram Number rogram Number rogram Number rogram Number - Panel index (used to view settings for all programs).
− Filter Filter Filter Filter Filter - Filter number
− Last Start Last Start Last Start Last Start Last Start - The previous start trigger for the indexed program (irrigation or
filter cleaning).
− At At At At At - The date and time moment of the previous start for the indexed pro-
gram.
− − − − − System clock. System clock. System clock. System clock. System clock.
TOTAL ACCUMUL – C17
From: 09-26 13:37:12
0007654L Irrig
13:15
TOTAL ACCUMUL C17
This panel provides a total (in time or volume) of the entire irrigation process
