Hanna Instruments HI 8050 - Manual (Page 35)

35
This panel provides a total (in time or volume) for each of the irrigation sec-
tors. The valve number indexes this panel. This panel contains the following
information:
− FFFFFrom
rom rom rom rom - Time stamp indicating the start of recording (statistics)
− Accumulation - Accumulation - Accumulation - Accumulation - Accumulation - Total accumulation in time or volume for the indexed
valve and type of accumulation selected on panel C17 (TOTAL
ACCUMUL).
− Sect Sect Sect Sect Sect - The sector number (label) / valve number (index for this panel).
− − − − − System clock. System clock. System clock. System clock. System clock.
TOTAL AVERAGES – C20
From: 09-26 13:37:12
05.3pH
02.1mS +21C 13:15
TOTAL AVERAGES C20
This panel indicates the overall average of pH, conductivity and temperature
for the entire irrigation process. This panel contains the following information:
− FFFFFrom
rom rom rom rom - Time stamp indicating the start of recording (statistics)
− pH pH pH pH pH - The pH total average
− mS mS mS mS mS - The EC total average
− C C C C C – The temperature total average
− − − − − System clock. System clock. System clock. System clock. System clock.
PROGRAM AVERAGES – C21
From: 09-26 13:37:12
05.3pH Prog 01
02.1mS +21C 13:15
PROGRAM AVERAGES C21
This panel provides a pH, EC and temperature average for each of the irriga-
tion programs. The program number indexes this panel. This panel contains
the following information:
− FFFFFrom
rom rom rom rom - Time stamp indicating the start of recording (statistics)
− pH pH pH pH pH - The pH average for the indexed program.
− PPPPProgram Number rogram Number rogram Number rogram Number rogram Number - Panel index (used to view settings for all programs).
− mS mS mS mS mS - The EC average for the indexed program.
− C(or F) C(or F) C(or F) C(or F) C(or F) – The temperature average for the indexed program.
− − − − − System clock. System clock. System clock. System clock. System clock.
