32
valve number assigned to that sector. This parameter indexes the sectors
for this panel.
− Set Set Set Set Set - Displays the amount of irrigation water set in time or volume for the
selected sector/valve of the indicated program.
− Irrigation correction value Irrigation correction value Irrigation correction value Irrigation correction value Irrigation correction value (number directly following Set value) - Dis-
plays correction value in time or volume for the selected sector/valve of
the indicated program.
− Done Done Done Done Done - Displays the current point of irrigation in time or volume for the
selected sector/valve of the indicated program.
− − − − − System clock System clock System clock System clock System clock
NO NO NO NO NOTE TE TE TE TE::::: The label of sector consists of a numeric “tag” for the assigned valve.
Sector labels can be specified using panel S43 S43 S43 S43 S43 (SET SECTORS). As default the
sector label will be identical to the corresponding valve number.
FERTILIZ STATE – C14
Prog 02 Fert 02
Set 40%
Current 20% 13:15
FERTILIZ STATE C14
This panel displays the set and current amount of fertilizer used for a specific
program. The Fertigation Controller controls the dosing of 4 fertilizers. In this
panel the fertilizer number is used as the index, allowing inspection of the
percent values for one up to four fertilizer tanks involved in the selected irriga-
tion program. This panel contains the following information:
- Program Number
- Program Number - Program Number - Program Number - Program Number
- F
- F - F - F - Fert ert ert ert ert - Panel index. Fertilizer tank number. Each program can control 1 to 4
fertilizer tanks.
- Set - Set - Set - Set - Set - The set percentage of one of four selected fertilizers to be dosed.
- Current
- Current - Current - Current - Current - The current dosage percentage of one of selected fertilizer, if the
fertilizer control mode is EC. If the fertilizer control is ratiometric or vol-
ume, then it will display “- -”.
- System clock. - System clock. - System clock. - System clock. - System clock.
NO NO NO NO NOTE TE TE TE TE: : : : : The fertilizers percentage values can be specified using the S39 S39 S39 S39 S39 (SET
FERTILIZERS).
AGITATOR STATE – C15 (only for HI8050)
Prog 08
WORK 00:03 WORK
PAUSE 00:02 13:15
AGITATOR STATE C15
