Hanna Instruments HI 8050 User Manual

Page 37

VIEW LOG DATE – C24

Log consulting date:

26-12

15:05

VIEW LOG DATE C24

This panel allows the user to view log data from a specific date. The SET

SET

SET key

is used to enter the date of choice thus entering the setting mode. After enter-
ing the panel and pressing the SET

SET

SET key, the cursor (focus) is shifted from the

panel number to the first place of the day indicator. The key pad and arrow

arrow

keys

keys can be used to enter the selected date followed by the ENTER

ENTER

ENTER key.

Once ENTER

ENTER

ENTER is pressed the Fertigation Controller will search for the logged

data and the panel will be automatically change to panel C26 (LOG) to see
the results. If no data is found “No records found” is displayed. This panel
contains the following information:
− LLLLLog consulting date

og consulting date

og consulting date - The initial viewing date set by the user.

− System clock

System clock

System clock.

ANOMALIES (ALARMS HISTORY) – C25

Low level fert: 4

CLEARED ALARM

26-12 14:36:22 13:15

ANOMALY 0193/22 C25

This screen display anomalies. Anomalies are considered alarm history

alarm history

alarm history.

This screen displays alarm conditions that are no longer active. Once viewing
the panel all of the anomalies (prior alarms) can be scrolled and viewed using
the UP

UP and DOWN

DOWN

DOWN or ENTER

ENTER

ENTER keys.

This panel contains the following information:
− Alarm Description

Alarm Description

−

− Cleared Alarm indication

Cleared Alarm indication

− Time stamp

Time stamp

Time stamp - Time of alarm occurrence.

−

− System clock

System clock

− ANOMAL

ANOMAL

ANOMALYYYYY - The anomaly log record number and (/) the number of all

anomalies since the system statistics were recorded.

LOG – C26

Log record

description

18-08 15:05:30 15:05

Log 0012 C26
