SECTOR AVERAGES – C22

From: 09-26 13:37:12

05.3pH Sect 01/01

02.1mS +21C 13:15

SECTOR AVERAGES C22

This panel provides an average pH, EC and temperature reading for each of
the irrigation sectors. The valve number indexes this panel. This panel con-
tains the following information:
− FFFFFrom

rom

rom - Time stamp indicating the start of recording (statistics)

− pH

pH - The average pH reading for the indexed valve.

− Sect

Sect

Sect - The sector number (label) / valve number (index for this panel).

− mS

mS - The average EC reading for the indexed valve.

− C

C – The average temperature reading for the indexed sector.

−

− System clock.

System clock.

ACTIVE ALARMS – C23

Low level fert: 4

ACTIVE ALARM

26-12 14:36:22 13:15

ALARM 02/07 C23

This displays the active alarms current in the system. Once viewing the panel
all of the alarms can be scrolled and viewed using the UP

UP and DOWN

DOWN

DOWN or

ENTER

ENTER keys. This panel contains the following information:
− Alarm Description

Alarm Description

−

− Active Alarm indication

Active Alarm indication

− Time stamp

Time stamp

Time stamp - Time of alarm occurrence.

−

− System clock

System clock

− ALARM

ALARM

ALARM - The alarm number and (/) total number of all active alarms.

When at least one active alarm is present, the system clock blinks “ALARM”.
This indication is displayed on all panels having the system clock.

NOTE

TE::::: The alarm management system is designed to provide self-update

behavior, thereby no user intervention is required to restore the status of the
interrupted program once the condition is resolved. If the condition of the
active alarms change, the panel will reflect the change accordingly without
user intervention. However certain alarms might cause the controller to enter
the STOP state. In this state the controller stops all activities and waits for the
user intervention.
