Page 38

This panel is meant to display the records from log after a search has been
started in panel C24 (VIEW LOG DATE). The UP

UP and DOWN

DOWN

DOWN arrow keys are

available to move between log records in a “select previous/next” manner.
This panel displays the following information:
− Log record -

Log record -

Log record - Log record description.

− Time stamp -

Time stamp -

Time stamp - Time stamp of logged occurrence.

−

− System clock.

System clock.

−

− Log record number

Log record number

GLP – C27

pH Slope :59.12mV/pH

pH Offset: +20mV

GLP C27

This panel is designed to view the parameters of the pH electrode so you can
see the state of the electrode. This panel displays the following information:
− pH slope –

pH slope –

pH slope – the slope of the pH electrode.

− pH offset –

pH offset –

pH offset – the offset of the pH electrode.

SETTINGS P

SETTINGS PANELS

ANELS

The Setting panels provide an interface by which the user can set up the
functionality of the Fertigation Controller to suite the application requirements.
The parameters in any setting panel can be modified only if the user presses
the SET key (entering the setting mode). Once the SET key is pressed the cursor
(focus) is passed to the first adjustable parameter on the panel. Using the
keypad along with the arrow keys the user can set the desired parameters and
navigate within the panel. The ENTER key validates all entries. In SET MODE
panel browsing methods are disabled until the user exits from SET MODE by
pressing the ENTER (validation) or ESC (cancel) key.

SET DATE & TIME – S28

Date: Fri-22-09-2000

Time: 17:03:20

18:07

SET DATE & TIME S28

This panel allows the setting of the following parameters:
− Date

Date

Date - Day / Month / Year format. The day name is automatically updated
