29
WORK TIME COND – C07
Prog 08 Time Y
Day Y
Period Y 13:15
WORK TIME COND C07
The program number indexes this panel. This panel contains the following
information:
− PPPPProgram Number
rogram Number rogram Number rogram Number rogram Number - Panel index (used to view settings for all programs).
− Time - Indicates if the selected program’s daily schedule is met at the actual
moment
− Day - Indicates if the selected program’s monthly schedule is met at the
actual moment
− Period - Indicates if the selected program’s yearly schedule is met at the
actual moment
− System clock
PRIOR&CONFLICTS – C08
Prog 08 Priority 06
Conflict Programs 09
13:15
PRIOR&CONFLICTS C08
This panel indicates the priority level of the indexed program. Priority settings
play a roll in program execution when two or more programs have similar
starting conditions. The priority for a given program can be set using panel
S31
S31 S31 S31 S31 (SET PRIORITY). The Conflict Programs counter cyclically displays all
programs that are in conflict with the currently active program. Programs can
be in conflict if their specific start and running conditions are synchronous.
Given this scenario, the program having the highest priority will become ac-
tive.
The program number indexes this panel. This panel contains the following
information:
− PPPPProgram Number
rogram Number rogram Number rogram Number rogram Number - Panel index (used to view settings for all programs).
− Priority Priority Priority Priority Priority - Displays priority of indexed program
− Conflict Programs Conflict Programs Conflict Programs Conflict Programs Conflict Programs - Cyclically displays the program number of programs
in conflict with the currently active program.
− System clock System clock System clock System clock System clock.
