30
IRRIG STATE – C09
Prog 08 IRRIG
Set 01:15:20+005:55
Done 00:45:10 13:15
IRRIG STATE C09
This panel displays the current irrigation state of the indexed program. Time or
volume can control irrigation and the above panel displays the set value and
the amount of irrigation currently completed. The mode of irrigation (time or
volume) can be selected using panel S55
S55 S55 S55 S55 (IRRIG CTRL MODE). The program
number indexes this panel. This panel contains the following information:
− PPPPProgram Number
rogram Number rogram Number rogram Number rogram Number - Panel index (used to view settings for all programs).
− Irrig Irrig Irrig Irrig Irrig - the state of the program: : : : : Irrig - irrigating; Preirrig - preirrigating;
Postirrig - postirrigation; Idle - irrigating or waiting for irrigation
− Set - Set - Set - Set - Set - Displays the required (set) value of irrigation in time or volume.
− Irrigation correction value Irrigation correction value Irrigation correction value Irrigation correction value Irrigation correction value (number directly following Set value)
− Done Done Done Done Done - Displays the value already done of irrigation time or volume.
− System clock System clock System clock System clock System clock
MAN CORRECTION – C10
Prog 08
+015%
+00:15:55 13:15
MAN CORRECTION C10
This panel displays how much the programmed irrigation parameters are
manually modified (corrected). The program number indexes this panel. This
panel contains the following information:
− PPPPProgram Number
rogram Number rogram Number rogram Number rogram Number - Panel index (used to view settings for all programs).
− Irrigation extension percentage Irrigation extension percentage Irrigation extension percentage Irrigation extension percentage Irrigation extension percentage - Displays the overall extension per-
centage of irrigation for the selected program due to manual correction.
− Irrigation extension value Irrigation extension value Irrigation extension value Irrigation extension value Irrigation extension value - Displays (in time or volume) the extension
value of irrigation for the selected program due to manual correction.
− System clock System clock System clock System clock System clock
TOTAL CORRECTION – C11
Prog 08
+035%
+02:00:13 13:15
TOTAL CORRECTION C11
