28
− − − − − System clock System clock System clock System clock System clock
REMINDER: In CONSULTING MODE the ESC key can be used as a
shortcut key to access this panel from any panel.
PH STATE – C05
Prog 08 Ref=06.4pH
pHout:06.4pH 13:15
PH STATE C05
The purpose of this panel is to allow the user to inspect the current pH refer-
ence point for a specific program and the real time pH sensor readings. The
program number indexes this panel. This panel contains the following infor-
mation:
− Program Number
Program Number Program Number Program Number Program Number – The current selected program. Act as index for the
panel (used to view settings for all programs).
− Ref Ref Ref Ref Ref = Reference or set point pH value for the specified program.
− Phout Phout Phout Phout Phout - Real time value of pH sensor. This reading applies to the entire
process and is not program specific.
− − − − − System clock System clock System clock System clock System clock
EC STATE – C06
Prog 08 Ref=05.6mS
ECin :01.1mS
Count:02.0mS 13:15
EC STATE C06
The purpose of this panel is to allow the user to inspect the current EC refer-
ence point for a specific program and the real time EC sensor readings. The
program number indexes this panel. This panel contains the following infor-
mation:
− PPPPProgram Number
rogram Number rogram Number rogram Number rogram Number - Panel index (used to view settings for all programs).
− Ref Ref Ref Ref Ref - Reference or set point EC value for the specified program.
− Ecout Ecout Ecout Ecout Ecout - Real time value of EC sensor. This reading applies to the entire
process and is not program specific.
− EC in - Real time value of EC input sensor. This sensor measure the conduc-
tivity of the incoming water supply. This reading applies to the entire
process and is not program specific.
− System clock
