Page 24

PANEL DESCRIPTIONS

Below are described all the panels in the controllers. The panels are divided in
three sections: Initialization panels, consulting panels and setting panels. The
data fields within each panel are described from left to right unless otherwise
specified.

INITIALIZA

INITIALIZATION P

TION P

TION PANELS

ANELS

INITIALIZATION PANEL

HANNA INSTRUMENTS

HI8050 V00.01-004E

INITIALIZATION:

Loading StringTable

This panel is shown during Fertigation Controller INITIALIZATION state and
contains the HANNA INSTRUMENTS logo and the name of the controller.
The last line is used to display the current status of the initialization sequence.
This panel is also used to display any possible errors that may occur during
the start up sequence.

START PANEL

HANNA INSTRUMENTS

HI8050 CONTROLLER

Fri 15-03-2000 13:15

STOP PRESS ENTER

This panel is displayed after successful initialization or whenever the password
authentication sequence fails (user will be logged off due to incorrect pass-
word entry). This panel displays the date and time and the bottom left corner
it is shown the Fertigation Controller functional state.
It is important to note that the Fertigation Controller is normally

It is important to note that the Fertigation Controller is normally

It is important to note that the Fertigation Controller is normally
functioning at this point if the required external conditions are

functioning at this point if the required external conditions are

functioning at this point if the required external conditions are
met even if the user is logged off.

met even if the user is logged off.

met even if the user is logged off. At this stage, when the user presses
the ENTER

ENTER

ENTER key another login opportunity will be given if the password au-

thentication process is enabled. This feature can be specified via panel S64

S64

(SET PASSWORD).
