FeiYu Tech FY-Panda2 Autopilot User Manual
Page 9
Guilin Feiyu Electronic Technology Co., Ltd
Guilin Feiyu Electronic Technology Co., Ltd http://www.feiyu-tech.com [email protected]
Page 7
10
Use for connect Data radio and USB data cable
11
GPS extension cord
12
Attention:
If you do not use the ESC to power on the servos,
you can connect external power source to power on the servos
through P2 port.
13
Connect to the taking photo port of the camera.(Need to do the
camera shutter transformation)
