FeiYu Tech FY-Panda2 Autopilot User Manual
Page 14
Guilin Feiyu Electronic Technology Co., Ltd
Guilin Feiyu Electronic Technology Co., Ltd http://www.feiyu-tech.com [email protected]
Page 12
The wire connection about GPS module.
2*4P RC receiver connecting wires, use for
connect the RC receiver and PandaⅡ,the wires
is arranged by the colors.
White (bundled with red & black)
——AIL；
Orange
——ELE； Green ——THR；
Yellow
——RUD； Brown ——CH5；
Blue
——CH6；
The FY-606 Data radio connecting wires.
The Airspeed sensor connecting wires.
The wire connection about camera control port
P1,white(signal),black(GND).
Vibration absorbing pads (dampers),use for
PandaⅡvibration damping installation.
