Page 14
Arrow forward（default direction）
Arrow towards to left Arrow towards to right
Arrow towards to back
Nose of the plane
9. The installation of main module
9.1 PandaⅡ module installation
The Autopilot
module must be placed horizontally and as close as possible to the plane‘s CG
(Center of Gravity). The default direction is the arrow direction must be pointing towards the nose of
the plane (i.e. direction of flight). You can change the direction to four directions via the GCS software,
i.e direction forward, back, left, right (shown below) .
When installing the autopilot module please make use of the supplied damper mount or other
DIY vibration damping device, especially on gasoline aircraft. Otherwise the vibrations will cause a
large data inconsistencies which will adversely affect the autopilot accuracy.
